| Specifications |
| Operating system | Android 5.1 |
| CPU model | Qualcomm Quad-Core ARM Cortex-A7 Processor |
| CPU Clock Range | 1.1GHz |
| RAM | RAM:1GB EMMC:8GB |
| LCD Screen | 5.0 inch |
| Display Resolution | 720*1280 |
| Fingerprint collection | Spatial resolution :508 DPI |
| module(optional) | Active sensor area :12.8mm*18.0mm |
| | (In compliance with FBI) |
| Communication | 4G/3G/2G/Hot spot/Bluetooth |
| GPS | Built-in GPS |
| USB | USB 2.0 HS,Micro USB(OTG),Mini USB serial port |
| Camera | Rear camera:5 Mega-pixel camera |
| Front camera:0.3 Mega-pixel camera |
| Support 1D / 2D scanning |
| Card Slot | SIM ×1;SAM×2;SD×1 |
| Touch screen | Capacitive touch screen, support the electronic signature |
| Printer | Built-in high speed thermal printer,58mm print paper |
| Magnetic card reader | Support 1/2/3 track,Bi-directional swiping |
| IC card read-write | support type A(5.0V),type B(3.0V) or type C(1.8V) |
| (In compliance with EMV and PBOC) |
| NFC card | Support ISO/IEC14443 Type A&B, Mifare1 |
| (In compliance with EMV and PBOC,with card reading indicator) |
| GPS | Built-in GPS |
| Multimedia | Support for recording, voice broadcast |
| Support video play back/recording |
| Password keyboard | Built-in password keyboard (virtual); |
| Support DES, 3 DES, RSA, SHA - 256 and AES;algorithm |
| Battery | Lithium battery, 2800 mAh, 7.4V |
| power adapter | Input:110V to 240V AC/50 ~ 60Hz |
| Output: 5 v DC / 2 A |
| General Micro USB interface |
| Dimension and weight | 191.6mm×80.2mm×46mm,424g |
| Standard Accessories | 1pc power adaptor,1pc User Manual,1pc Warranty card, |
| 1pc USB cable,1 roll 58mm thermal paper, |
| 1pc desk top charger(optional),1pc silicone protecting
case(optional) |
| Certificate | Unionpay Terminal Safety Certification |
| Unionpay POS Terminal Safety Assessment |
| EMV Contact Terminal L1&L2 |
| EMV Contactless Terminal L1 |
| PCI5.x |
| PBOC3.0 L1&L2 |
| CE,CCC,FCC |
| PayPass/PayWave(under certification) |
| FBI,STQC(Fingerprint module) |
